Paket SHS 10, 20, 30 WP

Tersedia Paket SHS 10, 20, 30 WP dengan rangkaian sederhana.

1. Paket 10 WP :

- Panel Surya 10WP

- Batery VRLA 12V-7/9Ah

- Controller 10A

- Lampu LED 3 Watt 2 unit

- Box Panel Rakitan

- Bracket dan Penyangga

2. Paket 20 WP :

- Panel Surya 20WP

- Batery VRLA 12V-12Ah

- Controller 10A

- Lampu LED 3 Watt 2-3 unit

- Box Panel Rakitan

- Bracket dan Penyangga

3. Paket 30 WP :

- Panel Surya 30WP

- Batery VRLA 12V-17Ah

- Controller 10A

- Lampu LED 3 Watt 3-4 unit

- Box Panel Rakitan

- Bracket dan Penyangga

Harga terjangkau dan bergaransi

Call : 031-99893288 / 082230261340

Email : marketing.dbs@yahoo.com

Battery VRLA merk Torace / Greentek

lampu PJU LED Lokal Murah

Lampu PJU LED Lokal Murah


- Kualitas kami jamin
- LED lampu bergaransi
- Harga dijamin murah
- Pembelian banyak ada discount
- Tanpa sertificat

PAKET PJU MURAH

Paket PJU Tenaga Surya Murah
- PJU 10 Watt
- PJU 20 Watt
- PJU 30 Watt
- PJU 40 Watt
- PJU 50 Watt
- PJU 60 Watt
- PJU 80 Watt
- PJU 90 Watt
- PJU 100 Watt


Paket murah dan bergaransi resmi
Penawaran harga bisa call T. 031-99893288 / 082230261340

Pemasangan Lampu PJU di Timika - Papua

Tiang Oktagonal Galvanies

Jual Tiang PJU Oktagonal Galvanis

lampu PJU LED Nikkon

LEDXION S437 SERIES
60W, 80W dan 90W LED STREET LANTERN

LED TECHNICAL DATA :

Typical Luminous Flux & Efficiency @700 Ma : 280 Im

Max Junction Temperature : 150ºC

Color Temperature : 3500K Warmwhite & 5300K Daylight

LED Life Cycle : 50,000 hrs

LUMINAIRE TECHNICAL DATA :

LED Light Source :

2 LED Modules x 30W 14 LUMILEDS LUXEON Rebel ES (60W)

2 LED Modules x 40W 18 LUMILEDS LUXEON Rebel ES (80W)

3 LED Modules x 30W 14 LUMILEDS LUXEON Rebel ES (90W)

Housing Material : Die-Cast alumunium finished with durable polyester epoxy power coating

Operating Temperature : -30º~+45ºC

Power Supply : AC : 90~305Vac 50/60Hz

Max System Power Consumption : 67W,84W,99W

Total Luminous Flux :

6200 Im-60W

7800 Im-80W

9200 Im-90W

Insulation Classification : Class 1

Ingress Protection : IP66 (Lamp&Gear Compartments)

Mounting Spigot

50mm

60mm spigot available upom special request

Pole Instaliation Detaile (mm)

Net Weight : 8.2Kg

Compliance Standard :

LED : LM 80

Driver : UL/CUL,CE,EN55015,3N61457

Luminaire : LM 79,EN 60598-01,EN 60598-2-3,EN62471,EN62493,EN6 100-3,EN61547

• Apllication :
• Parking Areas
• Facade Lightings
• Sport Lightings
• Commercial Area
• Resisdential Areas
• Jetties

• Photo Metric : Efficacy
• 93 Im/W (60W Model)
• 93 Im/W (80W Model)
• 93 Im/W (90W Model)

• Order Code :
• S437 60W-LEDXION K09125 60W
• S437 80W-LEDXION K09125 80W
• S437 90W-LEDXION K09125 90W
